19 Axes double heads wire bending machine

Our bending machine boasts powerful performance with high precision and efficiency, featuring 19-axis servo control and precision control within ±0.02mm. As the inventor of the Chinese rotary-head bending machine, we have always dedicated ourselves to research and development with a professional and rigorous attitude for 25 years, and now we have become the top-ranked brand of bending machines in China.

ꄲNext： Car skylight skeleton double head wire bending machine

TOP 1 Brand wire bending machines in CHINA

Wire Diameter	Wire Feeder	Straightening	Bending	Cutting	Model
Φ1.0~2.5mm	Yes	Yes	Yes	Yes	HT-3D-ST2020
Φ4.0~8.0mm	Yes	Yes	Yes	Yes	HT-3D-ST1480

Integrating functions such as feeding lines, straightening, bending, cutting, and programming into one, fully automated.
Automation uses various electronic systems to allow the development of its dedicated softwares.
All are driven by servo motors.

While focusing on high efficiency, we also take economic costs into consideration. Our machinesconsume on average over 30% less electricity compared to those of our competitors.
Standardized assembly processes and precision machining equipment ensure that the accuracy ofour machines can be controlled within 0.02mm and maintain good stability.

Model No.	HT-3D-ST1480	HT-3D-ST2020
Number of axis	14	20
Wire Size	Φ4.0~8.0mm	Φ1.0~2.5mm
The Max. processing length of wire	2500 mm	2500 mm
Accuracy	≤ 0.02mm	≤ 0.02mm
Number of feeding rollers	3 Pairs *2	3 Pairs
All servo motor driven	✓	✓
Wire feeding speed	90 m/min	90 m/min
Wire feeding Accuracy	300mm ± 0.1	300mm ± 0.1
Input Power	380V/420V/440V	380V/420V/440V
Weight of machine	5800 kgs	3500 kgs
Dimension of machine	463012001650mm	360023502070mm
The Max. load capacity of the decoiler	1000 kgs	1500 kgs
Weight of decoiler	900 kgs	1500 kgs
Dimension of decoiler	22002000900mm	24002200900mm
Intergrates with the wire feeding, straightening,bending and cutting.

Features:

1.It is for steel/stainless/ wire diameter from 1.0mm to 2.5mm.

2.With 20 axis 3D wire bending function, the option of chamfering, end forming, double head bending as your choice.

3.With remote function, PAD / Mobile phone / PC monitoring production by camera.

4.Auto uncoil, straighten, feeding, bending, cutting multi-function 3D CNC Steel Wire Bending Machine.

5.High precision;High efficiency:High durability;Full automatic;Easy to operate;Multiple applicable fields.

All the machines are designed by ourselves, and we have obtained 30+ CHINA patents.
ISO9001 and ISO45001 quality system are strictly followed.
40+ software rights are acquired.
CE compliance is applied to all our machines.

We are 24 hours & 365 days online.
If you have any problems with the use of the machine, we will feed back your problems with the machine within 24 hours and provide a solution within 48 hours.
We will provide the installation instructions for this machine. Guide to machine maintenance Common faults of machines are introduced.
Online training videos of machine, etc

The documents we provided:

Don't hesitate to place your order. Let's move forward together. Our machines will make your production easier.
